Starting the Linear Drive Revolution

The Horizon CMM breaks new ground in design and innovation using frictionless linear drives, which are the key to its fast and exceptionally smooth motion.

The kinematic isolated drive structure is completely independent of the CMM structure and ensures that the motor thrust is directed through the centre of gravity of the moving parts. This not only avoids acceleration induced metrology errors but also has the effect of thermally isolating the motors from the metrology structure of the CMM.

High-performance, High-accuracy

The Horizon is a standout machine with fast, smooth, silent motion ideally suited to contact scanning and with a first-term accuracy specification of under two microns.

Horizon CMM
Horizon CMM

Unrivalled Reliability

Linear motors are non-contact and therefore have no wearing parts and thus provide the perfect solution for CMM drives, improving reliability and reducing maintenance.

  • Linear motors offer frictionless, smooth, silent motion
  • Drives applied through the centre of gravity improves both speed and accuracy
  • Thermal isolation of motors from metrology structure
  • Smooth motion ideal for contact scanning
  • Aberlink's revolutionary easy-to-use measurement software
  • Shortest learning curve of any equivalent system - 1 day without prior CMM experience
  • Choice of Y axis sizes ranging from 1000mm to 2000mm
  • Suitable for the workshop environment
  • Industrial joystick supplied as standard
  • Free stylus change rack with every motorised probe head upgrade
  • Aberlink 3D measurement software for touch probe feature inspection
  • Windows based controller, machine controller card and peripherals
  • Steel CMM workbench with fixed monitor arm or control cabinet
  • Renishaw TP8 manual indexing probe head and integrated probe
  • Aberlink probe stylus kit
  • Aberlink Ø19mm sphere CMM requalification kit
  • User training course - up to 4 trainees and software user guide
  • 12 months full parts and labour warranty
  • Free telephone helpdesk support
  • Free software upgrades - no maintenance fees or contracts
  • Common Probe Options
  • RTP20
  • PH10T (w/TP20, TP200)
  • PH10M (w/SP25)
  • PH6M (w/SP25)

The Horizon can be supplied with any Renishaw touch trigger probe and probe head. For more help selecting the right probe, view our probe head comparison table.

Axis Travel (mm) X 800
Y 1000, 1500, 2000
Z 600
Overall Size (mm) X 1403
Y 1530, 2030, 2530
Z 2700
*Volumetric Accuracy TP20 (1.9 + 0.4L/100) µm
TP200 (1.8 + 0.4L/100) µm
SP25M (1.75 + 0.4L/100) µm
Scale Resolution 0.1µm
**Optimum Temp Range 18 - 22°C
Operational Temp Range 5 - 45°C
Table Solid granite
Table Load Capacity 1000kg
Max. Velocity Vector 1020mm/sec
Max. Acceleration Vector 1020mm/sec²
Air Consumption 50 l/min (1.8 cfm)
Required Air Pressure 5 bar (72 psi)

*Maximum Permissible Error MPEE within the thermal limits defined for optimum temperature range. **Installation environmental thermal limits: Rate of change <1°C/hr and <2°C/24hr. Temperature gradient <1°C/m
